Honda WX10 1" GX25 Petrol-Engined Water Pump with Carry Handle - 140 Lpm

The WX10 is a compact, lightweight 1" water pump powered by a GX25 4-stroke Honda engine, which pumps 120 litres a minute at 3.6 Bar / 54 Psi of pressure and a maximum 37m of head, 8m of suction. The WX10 is well-suited for applications like pool/spa drainage, irrigation, construction site dewatering, emergency water transfer, or general water movement tasks where portability and reliability are important. Comes with a 2 year domestic warranty (1 year commercial use).

MPN: WX10

Our Price: £389.77 excl VAT
Our Price: £389.77 inc VAT

Free Delivery

Please call for ETA on Pressure Washers, most are on a next day service but some can be 5 working days. Parts and accessories ordered before 2:30pm are usually dispatched the same day by the UK distributor, using next working day delivery or first class post on Mondays to Fridays.

Optional Extras (tick to add)

1" Aluminium Cam Lever Quick Release Hose Connection Kit + £35.08 (£35.08 + VAT)

1" Suction Hose - 10m Length + £36.40 (£36.40 + VAT)

Quantity

Add to Basket

Full Description
Specification

Honda WX10 1" GX25 Petrol-Engined Water Pump with Carry Handle - 140 Lpm

Pressure: 3.7 bar maximum / 54 Psi provides good pressure for irrigation, dewatering, or transfer applications
Head: 37m maximum lift capability means it can move water upward nearly 121 feet
Flow Rate: 120 LPM (31.7 GPM) maximum flow rate suitable for medium-duty applications
Suction: 8m suction lift after priming allows drawing water from wells or tanks below the pump level

Engine & Construction:

Honda GX25: Reliable 25cc 4-stroke petrol engine known for fuel efficiency and durability
Aluminum body: Lightweight yet corrosion-resistant construction
Cast iron volute & impeller: Durable components that handle abrasive conditions well
BUNA seals: Chemical-resistant elastomer seals suitable for various fluids
Stand: Rubberised feet on stand for minimise vibration

Practical Features:

1" ports: Standard threading for easy hose/pipe connections
Portable design: Baseplate with carry handle for mobility
Solids handling: Can pass particles up to 5.7mm, making it suitable for slightly dirty water
Silicon carbide mechanical seal: Long-lasting seal that handles higher pressures and temperatures

Specification

Maximum output capacity (L/min)	140
Inlet/outlet diameter thread type (mm/inches)	25/1-PF
Total head (m)	36
Suction head (m)	8
Pressure (bars)	3.6
Debris size capacity (mm)	6
Engine Model	GX25
Engine type	4-stroke, OHV,** 1 cylinder
Displacement (cm³)	25
Bore x stroke (mm)	35 x 26
Engine speed (rpm)	7000 max
Engine net power (kW)	0.72
Cooling system	Forced air
Ignition system	Transistor
Oil capacity (L)	0.1
Fuel tank capacity (L)	0.55
Operating time	1h20 approx
Starter system	Recoil
Sound pressure level at workstation (dB(A))	86
Guaranteed sound power level (dB(A))	102
Length (mm)	325
Width (mm)	220
Height (mm)	300
Dry weight (kg)	6.1
