The Pramac GB HPT 25 is a robust, user-friendly hand pallet truck engineered for standard material handling applications on smooth floors. Featuring a high-strength chassis built with fully automated robotics welding and a 2500 kg maximum lifting capacity, this industrial unit provides long-term structural reliability. An integrated proportional lowering valve and a multi-position foot pedal allow operators to execute precise, controlled load handling in warehouse and industrial environments.
- Load Capacity: 2500 kg maximum weight capacity for heavy industrial lifting.
- Fork Dimensions: 2000 mm length by 550 mm overall width to fit standard pallet sizes.
- Chassis Construction: High-strength steel built with 100% automated robotics welding for durability.
- Lowering Mechanism: Proportional valve and integrated foot pedal for smooth, controlled descent.
- Wheel Specification: Hard-wearing poly steer wheels and poly tandem load wheels for reduced rolling resistance.
- Low Profile Height: 85 mm minimum fork clearance to allow easy entry under low-clearance pallets.
Robotic Chassis Welding and Structural Strength
The frame of this hand pallet truck is manufactured using 100% automated robotics welding processes. This precision manufacturing technique ensures consistent weld penetration and structural integrity across the high-strength steel chassis. The resulting rigid frame is engineered to resist twisting and deflection under its full rated capacity of 2500 kg, providing long-term reliability in daily industrial environments.
Proportional Valve and Manual Controls
Load handling is managed through an integrated proportional hydraulic valve coupled with a traditional hand lever and foot pedal system. The proportional valve allows the operator to control the lowering speed precisely based on lever positioning, preventing sudden drops that could destabilize cargo. The covered tiller handle provides a standard operational interface, while the foot pedal offers an alternative, manual method to release hydraulic pressure and lower the forks smoothly.
Poly Steering and Tandem Rolling Gear
This unit is equipped with poly steering wheels and poly tandem load wheels, a configuration specifically suited for operation on smooth, level warehouse floors. Rubber compounds offer high structural hardness, which minimizes initial rolling resistance and rolling effort when moving maximum loads. The tandem wheel configuration distributes the weight across four separate load rollers, improving stability when traversing minor floor joints or uneven thresholds.
Fork Dimensions and Pallet Compatibility
With a an extra long fork length of 2000 mm and an overall width of 550 mm, the truck is sized for oversized open-bottom and perimeter-wired pallets. The forks feature a low profile minimum height of 85 mm from the ground, ensuring clean entry into standard pallet openings without catching. This truck maintains a balanced weight-to-capacity ratio that allows for straightforward manual maneuvering and precise positioning before lifting.
