The Premier 175XT 230V is a high-capacity, single-phase electric mixer featuring a powerful 2.0 hp motor and a reinforced 350L drum built to withstand heavy industrial loads. This robust machine delivers a consistent 180L mixing capacity and features an IP-sealed motor for enhanced protection against site dust and water. With its foot-operated tip-lock and extra-rigid chassis, it provides a stable, user-friendly solution for professional concrete, mortar, and plaster mixing in demanding site and rental environments.
- Reliable Electric Power: 230V single-phase motor delivering 2.0 hp (1.5 kW) for consistent material mixing.
- Expanded Batch Capacity: Large 350L drum providing a high-volume 180L maximum mixing output.
- Environmental Protection: Features an IP-sealed motor housing to protect internal components on-site.
- Reinforced Durability: Built with an extra-rigid drum and a 320 kg heavy-duty chassis to prevent distortion.
- Safety & Control: Equipped with a convenient foot-operated tip-lock for secure and easy drum positioning.
- Professional Standards: Maintains a steady 19 rpm for thorough blending of all material types.
Engine and Power
The Premier 175XT 230v 1ph Electric is equipped with a Electric 230V 1ph delivering 2.0 hp / 1.5 kW. This power unit provides reliable performance for consistent mixing operations across various material types and densities.
Drum Capacity and Output
Featuring a 350 litres drum with a maximum mixing capacity of 180 litres, this mixer operates at 19 rpm. The drum design incorporates reinforced construction to prevent distortion under heavy loads.
Construction and Durability
Built with a robust chassis designed to withstand tough site conditions, this heavy-duty site mixer features extra rigid drum construction and high-quality components. The unit weighs 320 kg with overall dimensions of 900mm x 1,500mm x 1,890mm (W x H x L).
Key Features
- Single phase 230V
- IP sealed motor
- Extra rigid drum
- Foot-operated tip-lock
Technical Specifications
| Motor Type |
Electric 230V 1ph |
| Power Output |
2.0 hp / 1.5 kW |
| Drum Capacity |
350 litres |
| Mixing Capacity |
180 litres |
| Drum Speed |
19 rpm |
| Weight |
320 kg |
| Dimensions (WxHxL) |
900mm x 1,500mm x 1,890mm |
Applications
This mixer is suitable for prolonged site usage and rental fleet operations. It handles concrete, mortar, and plaster mixing with consistent results.
